10 Ton 20 Ton European Standard Single Girder Overhead Crane 220V-440V 3Phase

10 Ton 20 Ton European Standard Single Girder Overhead Crane 220V-440V 3Phase
10 Ton 20 Ton European Standard Single Girder Overhead Crane 220V-440V 3Phase 10 Ton 20 Ton European Standard Single Girder Overhead Crane 220V-440V 3Phase 10 Ton 20 Ton European Standard Single Girder Overhead Crane 220V-440V 3Phase 10 Ton 20 Ton European Standard Single Girder Overhead Crane 220V-440V 3Phase 10 Ton 20 Ton European Standard Single Girder Overhead Crane 220V-440V 3Phase

Large Image :  10 Ton 20 Ton European Standard Single Girder Overhead Crane 220V-440V 3Phase

Product Details:
Place of Origin: CHINA
Brand Name: KORIGCRANES
Certification: ISO/CE
Model Number: HD
Payment & Shipping Terms:
Minimum Order Quantity: 1 set
Price: USD 2,000~10,000 /SET
Packaging Details: Main beams are packaged by plastic cloth; Electric parts are packaged by fumigation wooden box.
Delivery Time: 20 working days
Payment Terms: L/C, T/T, Western Union
Supply Ability: 100 set per month

10 Ton 20 Ton European Standard Single Girder Overhead Crane 220V-440V 3Phase

Description
Keywords: European Standard Single Girder Overhead Crane Max. Lifting Load: 1T-20T/ Customized
Working Class: A5 Span: 7.5-32.5m
Traveling Speed: 0~20 M/min Lifting Speed: 0.5/8m/min
Color: Yellow Or Customized Power: 3P 220--440 V/50hz/60HZ
Sling Type: Wire Rope Packing: Export Standard
Condition: New Warranty: 1 Year
High Light:

European Standard Single Girder Overhead Crane

,

Single Girder Overhead Crane 440V

,

European Standard 10 Ton Overhead Crane

European Standard Single Girder 10 ton Overhead Crane EOT Traveling Crane



European Standard Single Girder Overhead Crane Introduction



The European standard A3 class single girder 10 ton overhead travelling crane consists of a crossbeam, an electric hoist, a long travel mechanism, a driver's cab or manual control and an electrical control system. The electric hoist can be moved horizontally on a track mounted under the crossbeam. This type crane holds many characters of light structure, easy to install and maintain, which is typically used for either manufacturing or maintenance applications, where efficiency or downtime are critical factors, for instance, plants, warehouses, or material stocks. The beam adopts the whole type without welding, which structure is more reasonable and reliable. Cabin, radio controller or hand controller can be used for operating. The cabin has seats inside. Floor adopts insulation pads and toughened glass for windows; extinguisher and fan are equipped. Other accessory equipments like air-condition, buzzer, interphone can be configured according to our client’s request! The travelling motor can be standard motor,soft starter motor or work with frequency controller to meet the different speed requirements.



European Standard Single Girder Overhead Crane Parameter



Product name

HD European Overhead Crane

Lifting capacity

1~20ton

Lifting height

6-18m

Span

7.5m-28.5m

Working class

A5 (FEM 2M)

Crane material

Q235B

Lifting mechanism

ND european standard hoist

Trolley speed

2~20m/min

Crane speed

3~30m/min



High Safety, Reliability, Efficiency and Maintenance Free



1. Germany ABM Hoist lifting motor double-winding squirrel-cage pole-changing dual speed hoisting motor with stable and reliable operation, and free of maintenance. SEW variable speed inverter controlled travelling motors with stable and reliable operation and low noise.

2. Safety monitoring systems for hoisting and travelling mechanism, many functions can be achieved according to the demands of users.

3. The crane provides with many protection including linkage, overload protection, zero protection and limit protection, ensuring the crane always under safety operation.

4. The crane provides with advanced PLC automatic detection function, which can perform measurement, calculation and monitoring to the performance, safety and working condition in order to ensure more safe and reliable transportation of items.

5. The Crane Standard working duty is FEM 2M/ISO M5, equipped with our ND or NR series electric rope hoist with 1,600 hours of service at full load.

6. Standard dual speed for hoisting and variable frequency drive (VFD) control speed for cross and long travelling. Which improve load handling and reduce load sway motions.

7. Electric Components. Electrical components uses ABB, Siemens and Schneider international brands.



European Standard Single Girder Overhead Crane Details

10 Ton 20 Ton European Standard Single Girder Overhead Crane 220V-440V 3Phase 010 Ton 20 Ton European Standard Single Girder Overhead Crane 220V-440V 3Phase 1
