|Product Name:||Container Gantry Crane RMG Crane Rail Mounted Container Gantry Crane||Keywords:||Rubber Tyre Gantry Crane|
|Application:||Port,yard||Lifting Mechanism:||Electric Winch Trolley|
|Control Method:||Cabin / Remote Control||Working Duty:||A6 A7 A8|
|Working Temperature:||-20℃~+40℃||Capacity:||35t 40.5t|
|Span:||22m 30m||Wok Duty:||A6 A7 A8|
Rubber Tyre Container Gantry Crane,
Portal Container Gantry Crane,
Rubber Tyre Gantry Crane 40.5t
30 T 40.5t Portal Container Gantry Crane Rubber Tyre Gantry Crane A6 A7 A8
30 Ton 40 Ton 50 Ton Container Portal Crane Rail Tyre Container Gantry Crane
Rail Mounted Container Gantry Crane Description
Rail Tyre Container Gantry Crane(RMG) is a kind of rail mounted crane used to offload, stack and load 20ft, 40ft, 45ft ISO standard containers. Its provision of power is offered by cable reel. The crane contains three mechanisms: hoisting, trolley travelling and gantry travelling. The trolley running along the track mounted on gantry beam is capable to serve among legs. The crane is able to make straight movement along rails.
Portable 40 ton mini container gantry crane is powered by a 490BPG diesel engine and features low operating noise and low vehicle vibration. The main body consists of steel frame, steel wire rope, hydraulic motor of hydraulic transmission system, gear pump, steering cylinder, lifting cylinder, double-acting balance valve and walking solid tire. The lifting mechanism adopts four cylinders with the diameter of 180 mm, which have a large lifting capacity, a small system pressure, a stable and safe lifting and lowering, and high loading and unloading efficiency. It adopts two-wheel drive, four-wheel steering, and a large rotation angle of up to 110 degrees. It can realize steering and translation at any angle, and the turning radius is small. The control system consists of a complete set of valve body and operating rod, which is simple, convenient and flexible to operate.
Wheeled container gantry crane (referred to as yard bridge) is suitable for port, wharf, logistics and other container yard or transfer station of international standard container handling and loading and unloading. It is supported on the inflatable rubber tire, often powered by diesel generator, and can also be powered by cable reel and lithium battery. It is composed of large car mechanism, small car assembly, gantry frame, power system and special container spadders.
Design, manufacture and inspect FEM, DIN, IEC, AWS, GB and other latest domestic and foreign standards. Weihua RTG has various functions, high efficiency, stability and reliability, a wide range of operations, good mobility, little sensitivity to ground unsmoothness, convenient use, maintenance, maintenance, the biggest characteristics of straight, horizontal, 0-90 degree steering and in situ rotation.
With perfect safety indication and overload protection device, to ensure the maximum safety of operators and equipment. Electric drive adopts full digital AC frequency conversion, P LC control speed regulation unique technology, flexible control, high precision. Standard with domestic and foreign famous brand purchased parts to ensure the quality of the machine.
Rail Tyre Container Gantry Crane Technical Parameters
|Type of Container||20' 40' 45'|
|Power||3-Phase A.C. 380V 50Hz|
Rail Mounted Container Gantry Crane Advantages
* Rated load lifting capacity:40tons.
* High efficiency of handling,stacking and overturning operations for over length,over width or overweight.subjects.
* Extensive use with good unitprice,low operating cost,quick investment return.
* Full hydraulic drive with 3 Supportpoint design assures maximum stability and fully landing of the wheels.
* Swerve radius minimum, maximum tonnage capacity with narrow andlimited passageway space.The solid tire wheel designwith 8 wheels combination, which has large diameter, wide wheel surface, highelasticity and high load-bearing, reduces the grounding specific pressureduring heavy load operation and reduces the requirement of working ground road.
* Adjustable operation speed,zero speed braking,noneed brake maintains.
* When using wire rope, themaximum turning angle of 20-foot container is 45 degrees, and that of 40-footcontainer is 26 degrees, which basically meets the requirement of one-timeturning loading and unloading of bulk cargo.
* Frame modular demountablestructure,easy installation.
* Wireless remote control ofreliability and handl eability dual control lever with real-time operatingsystem,achieves unlimited sight.
* whole product with propersize and maneuverability.
* Can add extra weigher andheight restriction digital indicator safety system.
* With electric system PLCprogram design inside.
* According to user requirements can be customized design and manufacturing
Rail Mounted Container Gantry Crane Images
