Product Details:
|
| Name: | 2000 Kg Stationary Jib Crane | Lifting Capacity: | 2000 Kg |
|---|---|---|---|
| Lifting Speed: | 8 M/min | Traveling Speed: | 20 M/min |
| Longitude Traveling Speed: | 0.5 R/min | Warranty: | 1 Year |
| Control: | Pendant Control Or Remote Control | Color: | As Per Your Requirements |
| High Light: | 2 Ton Jib Crane High Safety,Shipbuilding 2 Ton Jib Crane,Shipbuilding pillar jib cranes |
||
Product Description
Jib cranes are widely used in ports, electric power, steel, shipbuilding, petrochemicals, mining, railways, construction, metallurgy and chemical industries, automobile manufacturing, plastic machinery, industrial control, highways, large-scale transportation, pipeline auxiliary equipment , slope tunnels, shaft management and protection, marine rescue, marine engineering, airport construction, bridges, aviation, aerospace, venues and other important industries.
Characteristics
Unique structure, high safety, reliability, high working efficiency, energy saving and time saving, flexible operation, etc.3 ton foundation mounted i beam 5 ton cantilever jib crane
* Compact Design
The compact structure design makes pillar jib crane light in dead weight and excellent in work performance, improves space utilization rate and narrows hook operation distance to the maximum intently. The best material handling solution for your applications.
* Smooth, Fast Loading, excellent performance
Stepless frequency conversion control system is installed to the crane and trolley, which make pillar jib crane brake stably, locate accurately, perform reliably, and travel steadily, position quickly, and solve the problem of swing of loads.
* Safer, Reliable, Using Free Maintenance Design
Best technology is adopted which makes the frequent operations safe and efficient.
Perfect braking systems can largely improves pillar jib crane safety and reliability, equipped with dustproof design, the working life can reach up to 1 million times.
Hardened and polished tooth surface ensures the operation of crane smoothly without troubles.
Specification
| Lifting Capacity | t | 1 | 2 | 3 | 5 | ||||
| Lifting Height | m | 5 | 5.5 | 5 | 5.5 | 4.5 | 5 | 4.5 | 5 |
| Work Radius | m | 4 | 4.5 | 4 | 4.5 | 5 | 5.5 | 5 | 5.5 |
| Crane Duty | GB | A3 | |||||||
| Lifting Speed | m/min | 8 | |||||||
| Traveling Speed | m/min | 20 | |||||||
| Rotation Speed | m/min | 0.5 | |||||||
| Rotation Angle | ° | 180, 270, 360, Adjustable | |||||||
Shpping Photos
